SOFT ICE CREAM MACHINE
PRODUCT MODEL OP138C STANDARD GB/T20978-2021
ELECTRICAL 220V~/50Hz PRODUCTION 38L/h
RATED INPUT POWER 2500W RATED INPUT CURRENT 14A
MOTOR POWER 1100W FAN RATED POWER 130W
REFRIGERANT R404A 0.85kg COMPRESSOR POWER 1060W
COOLING AIR CYLINDER NUMBER 2
COOLING CAPACITY 125W COOLING REFRIGERANT R134a/70g
DIMENSIONS 750 x 560 x 1420mm POWER CONSUMPTION 0.145kw.h/kg
NET WEIGHT 166kg USE CONDITION 10°C~38°C


WE HAVE PLEASURE IN OFFERING OUR VARIOUS PRODUCTS USED IN THE FIELD OF ICE CREAM PRODUCTION


With unique evaporation cooling technique and a digital control system. The machine is fitted with an electronic temperature and consistency control system & the hardness level of the ice cream can directly be chosen from the panel. The machine has a capacity of 38 Ltrs./hr. and which means that it can serve a continuous stream of customers.

The machine does not require an air pump as a 60% over run is obtained with special design & when sufficient and required air is injected through the air tubes, in the mix chambers.

The latest model machine is provided with two compressors where one compressor is for the production of Ice Cream and the second for cooling of the mix storage vessels. This compressor can be left ON at night and thus the mix will not spoil.
Since the machine is digital, it is suggested that a servo voltage stabilizer be provided along with.

2.5 Gallon Batch Freezer
1.5 Gallon Batch Freezer
Batch Type Ice Cream Churner
Ice Cream Moulds with Stick Holder
Pasteuriser – 150 LTRS.
Ageing Vat – 150 LTRS.
Ice Cream Mix Plant
Ice Candy Plant
Homogenizer
20-LTRS. Ice Cream Making Machine
Plate Heat Exchanger
